#98477501 | Dimensions: 71 x 71 x 76,5 mm

Large conduit box

P 71 GRO-K

Large conduit box , especially for horizontal factory finishing, 1-part, diameter 60 mm Ø, 4 screw bosses with a 60 mm screw spacing, combinable, suitable for opposing formwork, combinable with...

Login to see price

Remember product

Description

Large conduit box , especially for horizontal factory finishing, 1-part, diameter 60 mm Ø, 4 screw bosses with a 60 mm screw spacing, combinable, suitable for opposing formwork, combinable with a standard spacing of 71 mm, protection class IP30, rated insulation voltage: 400V AC, certified by VDE (DIN EN 60670-1/-22 (VDE 0606-1/-22)), Halogen free

with enlarged terminal compartment, adhesive fixing, conduit adapter and additional conduit adapter with Easy-Cut-Membran, sealing range M32 - M40

Technical Data

electrical characteristics

Rated insulation voltage AC	400 V
Type of protection	IP30
Suitable for	Concrete construction
UL Type Rating	not specified

Dimensions

Width	71 mm
Length	71 mm
Height	76.5 mm
Inner height	72.9 mm
Weight	0.059 kg

Material characteristics

Halogen free	yes
Flammability class according with UL94	HB
Glow-wire flammability	650 °C (EN 60695-2-11)

mechanical properties

Type of fastening	adhesive fixing

Ambient conditions

max. relative humidity 40°C	50 %
Min. ambient temperature	-25 °C
Max. ambient temperature	40 °C
24h ambient temperature	35 °C

Sales Information

EAN	4013902597536
ETIM Class	EC002601
Custom tariff number	39269097
Minimum order quantity	1

Material

Base unit material	Plastic
Cover material	Polypropylene

Certificates

Test mark	VDE (DIN EN 60670-1/-22 (VDE 0606-1/-22))

Logistic data

Outer packaging

EAN / GTIN	4013902597543
Width	0.79 m
Weight	5.15 kg
Height	0.29 m
Quantity	65 pieces
Depth	0.39 m

Pallet

EAN / GTIN	4013902597550
Width	0.8 m
Weight	114.7 kg
Height	1.89 m
Quantity	1170 pieces
Depth	1.2 m

Piece

EAN / GTIN	4013902597536
Width	0.071 m
Weight	0.059 kg
Height	0.077 m
Quantity	1 pieces
Depth	0.071 m
