Description
Threaded base M5
with M5 threaded bushing to take a ceiling hook, converts every U71 junction box to a ceiling socket
#97911001 | Dimensions: 70,7 x 70,7 x 23,5 mm
Thread bottom
Technical Data
Dimensions
| Width | 70.7 mm |
|---|---|
| Length | 70.7 mm |
| Height | 23.5 mm |
| Weight | 0.01 kg |
Material characteristics
| Flammability class according with UL94 | HB |
|---|---|
| Glow-wire flammability | 650 °C (EN 60695-2-11) |
mechanical properties
| Type of accessory | other |
|---|
Sales Information
| EAN | 4013902210206 |
|---|---|
| ETIM Class | EC002328 |
| Custom tariff number | 39269097 |
| Minimum order quantity | 100 |
Logistic data
Outer packaging
| EAN / GTIN | 4013902349005 |
|---|---|
| Width | 0.357 m |
| Weight | 1.495 kg |
| Height | 0.127 m |
| Quantity | 100 pieces |
| Depth | 0.257 m |
Pallet
| EAN / GTIN | 4013902349012 |
|---|---|
| Width | 0.8 m |
| Weight | 125.64 kg |
| Height | 1.67 m |
| Quantity | 10800 pieces |
| Depth | 1.2 m |
Piece
| EAN / GTIN | 4013902210206 |
|---|---|
| Width | 0.071 m |
| Weight | 0.01 kg |
| Height | 0.024 m |
| Quantity | 1 pieces |
| Depth | 0.071 m |
