Description
Twist plug, IP54, M_ x 1.5 mm, with closed sealing membrane, grey
Sealing range 22 - 35 mm, Thread length 18 mm
#20345001 | Dimensions: 55,8 x 55,8 x 31 mm
Twist plug
Technical Data
electrical characteristics
| Type of protection | IP54 |
|---|
Colours
| Accessory colour | light grey |
|---|
Dimensions
| Width | 55.8 mm |
|---|---|
| Length | 55.8 mm |
| Height | 31 mm |
| Weight | 0.0015 kg |
Material characteristics
| UV-resistant | no |
|---|---|
| Halogen free | yes |
mechanical properties
| for wall thickness max | 13 mm |
|---|---|
| for wall thickness min | 1 mm |
| for sealing range min | 22 mm |
| for sealing range max | 35 mm |
Ambient conditions
| Installation location | Indoors |
|---|
Sales Information
| EAN | 4013902859962 |
|---|---|
| ETIM Class | EC000451 |
| Custom tariff number | 39269097 |
| Minimum order quantity | 10 |
Logistic data
Piece
| EAN / GTIN | 4013902859962 |
|---|---|
| Width | 0.056 m |
| Weight | 0.0015 kg |
| Height | 0.031 m |
| Quantity | 1 pieces |
| Depth | 0.056 m |
Inner packaging
| EAN / GTIN | 4013902353378 |
|---|---|
| Width | 0.115 m |
| Weight | 0.191 kg |
| Height | 0.165 m |
| Quantity | 10 pieces |
| Depth | 0.083 m |
Outer packaging
| EAN / GTIN | 4013902332861 |
|---|---|
| Width | 0.357 m |
| Weight | 1.337 kg |
| Height | 0.127 m |
| Quantity | 60 pieces |
| Depth | 0.257 m |
Pallet
| EAN / GTIN | 4013902332878 |
|---|---|
| Width | 0.8 m |
| Weight | 167 kg |
| Height | 1.67 m |
| Quantity | 6480 pieces |
| Depth | 1.2 m |
Downloads
Download Data Sheet
Dimensioned drawing
Similar products
Twist plugWST M16
Twist plug
WST M16
Productnumber 20341601
Sealing range 5 - 10 mm, Thread length 9 mm
Twist plug, IP54, M_ x 1.5 mm, with closed sealing membrane, grey
Twist plugWST M20
Twist plug
WST M20
Productnumber 20342001
Sealing range 8 - 13,5 mm, Thread length 12 mm
Twist plug, IP54, M_ x 1.5 mm, with closed sealing membrane, grey
Twist plugWST M25
Twist plug
WST M25
Productnumber 20342501
Sealing range 9 - 16 mm, Thread length 12 mm
Twist plug, IP54, M_ x 1.5 mm, with closed sealing membrane, grey
Twist plugWST M32
Twist plug
WST M32
Productnumber 20343201
Sealing range 17 - 24 mm, Thread length 14 mm
Twist plug, IP54, M_ x 1.5 mm, with closed sealing membrane, grey
Twist plugWST M40
Twist plug
WST M40
Productnumber 20344001
Sealing range 17 - 24 mm, Thread length 14 mm
Twist plug, IP54, M_ x 1.5 mm, with closed sealing membrane, grey
Twist plugWST M63
